DY Series Semi Automatic Soap Filling Machine

Filling Range:5-30ml;30-200ml;200ml-2000ml;
Material: Stainless Steel 304 Or 316
Air pressure: 0.4-0.6Mpa
Filling speed:0-50Bottles/Min
  • DY

  • Y

  • 100-11

Availability:
Quantity:
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
sharethis sharing button

                                               DY Series - Semi Automatic Soap Filling Machine

Filling Range:5-30ml;30-200ml;200ml-2000ml;



DY Series - Semi Automatic Soap Filling Machine  Mainly feature


·  DY series fillers are semi-automatic piston fillers. Material is extracted and extracted by a piston driven by the cylinder, material flow is controlled by a check valve, and filling volume is regulated by the stroke of the cylinder controlled by a magnetic spring switch.

·  The design of this machine is reasonable, the model is compact, and the operation is convenient. The pneumatic components are all made of FESTO from Germany and AirTac from Taiwan.

· The material contact part is made of 316L stainless steel material, which meets GMP requirements.

· The filling volume and filling speed can be adjusted arbitrarily, with high filling accuracy.

· The filling head adopts anti drip and lifting filling devices.



DY Series - Semi Automatic Soap Filling Machine  Mainly specification


· Voltage: 220/110V 50/60Hz

· Power: 10W

· Filling speed: 10-50 bottles/min

· Filling accuracy: <±1ml

· Material contact part adopts 304&316 stainless steel material.

· With adjustment handle of filling volume, the filling speed can be adjusted.

· Automatic feeding, filling, uniform discharge, emergency stop,  filling quantity and speed can be adjusted.

· Filling head adopts a cylinder valve or a mechanical valve, leak proof plugging head is provided with a filling head, to prevent the filling head wire drawing, dropping material.

· All parts are connected by a hoop, convenient assembly disassembly, cleaning, maintenance, assembly.

· The machine set (manual) and (automatic). (manual) by foot control filling, (automatic) is a continuous filling machine.

Modle
Filling range(pcs/min)
Working speed(pcs/min.)
Air supply(Mpa)
DY-1-15
5-150
0-40
0.4-0.6
DY-1-25
10-250
0-30
0.4-0.6
DY-1-50
50-500
0-30
0.4-0.6
DY-1-100
100-1000
0-25
0.4-0.6
DY-1-250
250-2500
0-20
0.4-0.6
DY-1-500
500-5000
0-15
0.4-0.6




DY Series - Semi Automatic Soap Filling Machine  Application field


1. Cosmetics industry: lotion, facial cleanser, essence, moisturizing cream, hand cream, toner, perfume, alcohol gel hand sanitizer, etc.

2. Daily chemical industry: shampoo, conditioner, laundry detergent, hand sanitizer, detergent, shower gel, glass cleaner, car wash, bleach, detergent, shampoo, plant liquid fertilizer, toilet cleaner, alcohol gel hand sanitizer, etc.

3. Pharmaceutical industry: emulsion, suspension, injection, oral syrup, oral liquid, gel, etc.

4. Food industry: sauces, condiments, food slurry, nutrient solution, food, chocolate, sugar, wax products, dairy products, fruit juice, jam, milk drinks, etc.

5. Chemical industry: paints, coatings, dyes, inks, silicone oils, resins, lubricants, nanomaterials, etc.


DY Series - Semi Automatic Soap Filling Machine  Structural characteristics
